UIW300 Ultrasonic Sealing SystemUIW300 Ultrasonic Sealing System



Technical Specifications :-

Power Supply 230V 4A AC, 50/60 Hz
Rate Output Constant 100W, Peak 200W
Ultrasonic Power 25% - 100% variable
Operating Frequency 40kHz ± 2kHz
Mech. Amplitude at Sonotrode Max. 40 µm P-to-P
Generator Safety Classification IP 20, with ground
Transducer Safety Classification IP 65
RFI Suppression Meets EN 55011 & EN 50082-2
Operating Temperature +5 to +40°C
Ambient Conditions 10 to 90% relative humidity
Weight Transducer w sonotrode : 1,2 kg
Generator : 9 kg
Dimensions (LxWxH) Transducer : 195 x 41 x 62 mm
Sonotrode : D28mm x 53 mm
Generator : 480 x 370 x 160 mm
Control Console : 210 x 85 x 30 mm
Sealing Unit LM60 : Linear DC Motor w Encoder
Step Resolution : 0,2 µm
Speed : 13mm/s
Control : Automatic, fully integrated
Dimensions : 76 x 40 x 195 mm
Weight : 0.8 kg
Certification CE
FunkStörG, EMVG
